For line-haul and regional applications, the X15 Efficiency series offers ratings of 400 to 500 hp and 1,450 to 1,850 lb-ft. Peak torque is available at 1,000 rpm. Feature stories and news releases about Cummins people, technology and culture. ISX15 (2013) Power 400 - 600. Specifications Ratings Features Maintenance. Cummins ISX15 485 Pdf User Manuals. View online or download Cummins ISX15 485 Reference Manual. View and Download CUMMINS ISX15 600 reference manual online. ISX15 600 engine pdf manual download. Also for: Isx15 550, Isx15 525, Isx15 500, Isx15 485, Isx15 450, Isx15 425, Isx15 400, Isx15 500st, Isx15, 485st, Isx15 450st, Isx15 425st, Isx15 400st, Isx15 500v, Isx15 455v, Isx15 455. Cummins E-Mail – For online assistance with Cummins-related questions, click on the Contact Us link in the header at everytime.cummins.com. Cummins Web Site – For product literature or additional information, log on to everytime.cummins.com. Cummins Online Registration – Register all your Cummins engines quickly and easily at.

Cummins has built a reputable name for itself over the decades, but how did it get to where it is today? In this guide, we’ll discuss how Cummins started as a strong partnership, then transformed into an impressive engine manufacturing company. Diesel Pro Power will take you through the ISX series’ specs, common issues and featured products, whether you have one of the original units or a modern version.

When you know the ins and outs of your engine system, you can better prepare your marine or generator applications to make functional repairs when necessary.

A Brief History

Clessie Cummins founded Cummins Engines in 1919 and partnered with J. Irwin Miller, a knowledgeable man in business practices. By combining Cummins’ expertise in diesel and Miller’s business skills, they were able to expand the company to how we know it today. Through the decades, the Cummins brand has integrated itself into a multitude of areas within the diesel industry.

For example, in 1973, Cummins bought Holset Engineering Co., which was a company focused on engineering engine parts. Cummins also acquired Onan in 1986, a company that manufactured generator sets. The name was later changed to Cummins Power Systems.

In 1989, Cummins began working with Dodge Ram, and the name soon changed to Cummins Emissions Solutions.

Cummins is an engineering company that has its foot in multiple critical areas of the market. With growing expertise in engine manufacturing, emissions solutions, gensets and parts engineering, Cummins excels in manufacturing products and solutions for marine engines and generators.

Cummins ISX History

The initial design of the Cummins ISX began in 1998. The original engine in the series was the N14, but over time, it became an obsolete line of engines, as stricter Environmental Protection Agency (EPA) laws came into play.

In 2002, the ISX15, also known as the “Signature” series, started production. It upheld its name because it had an innovative fuel system called the “Interact System.” The “IS” in ISX stands for “Interact System.”

Since its launch, the ISX has been the core of Cummins’ diesel engine fleet. Not only has it advanced with quicker processing, but it has also increased fuel efficiency since its debut.

In 2002, the ISX became one of the first diesel engines to incorporate an exhaust gas recirculation (EGR) cooler system. The technology takes the engine’s exhaust and recirculates it back to the intake chamber, reducing NOx particles. The ventilated exhaust lowers the combustion chamber temperature.

The ISX started featuring the selective catalytic reduction (SCR) system in 2006. It injects urea, which is an active element in diesel exhaust fluid (DEF), into the exhaust. Ammonia in the urea chemically reacts with the NOx particles and converts them into nitrogen and water inside the catalytic converter. DEF reaches high temperatures in the holding tank, then pumps into the injector and decomposition tube, causing it to react to the NOx in the exhaust.

New advancements in emissions technology emerged when Cummins introduced the diesel particulate filter (DPF). The system captures the exhaust produced from the combustion chamber and neutralizes the soot through oxidation. The oxidized ash transforms into dust. Then, it’s regenerated through the turbo in a process known as regeneration.

The ISX had a dual overhead camshaft design. One cam activated the injectors, and the second initiated the valve train. This complicated injection system was cam actuated to form injection pressure and deliver fuel. However, it didn’t last into the next ISX versions after 2010.

The Cummins engine underwent a redesign to meet the 2010 EPA standards through developments in the emissions technology. The company’s advancements focused on a single overhead camshaft instead of a dual solution. They also innovated the common rail fuel system, which eradicated the need for an injector camshaft to generate pressurized fuel.

In the common rail fuel system, diesel fuel becomes pressurized via multiple piston pumps. Then, it’s distributed through the tubing to the rail system for storage under extreme pressures— about 35,000 PSI or higher.

This version of the ISX relies on an engine control module (ECM) to monitor the timing and pressure. The ECM can activate each fuel injector up to five times per combustion cycle. The single camshaft improvement creates a better fuel economy and reduces emissions to stay parallel with EPA standards.

By 2013, the ISX gained on-board diagnostics to track the engine’s emissions. This change increased fuel efficiency compared to previous versions. Each year, Cummins continues to update the ISX15 to meet EPA standards.

Cummins ISX Specs

A Cummins ISX engine is an Inline-6 diesel with a duel-fuel configuration — meaning it can run on diesel or natural gas — although, diesel is the most common. If you’re in the market for an ISX, its specification log includes:

– 400-600 hp

– 2,050 lb.-ft. maximum peak torque

– 2,000-2,100 RPM engine speed

– 1,000 lb.-ft. clutch engagement torque

– Six cylinders

– 14 gallons of oil capacity

– 15-liter design

– 3,093 lbs. system weight

– 3,021 lbs. dry weight

– 72 lb. aftertreatment

Throughout each improved generation, the ISX engine now has several prominent features that make it one of the most sought-after solutions. Compared to the original N14 series back in the late 1990s, the ISX now delivers an exceptional line of components that have been engineered and upgraded each year, including:

Cooled exhaust gas recirculation:If your engine was made after 2002, it has an EGR system. Recirculation within the engine lowers the combustion temperatures, which reduces optimized MPG and emissions.

Crankcase ventilation system:The ISX’s advanced crankcase ventilation only needs replacement after every third or fourth oil change, allowing you to operate for longer.

Cummins isx 15 torque specs torque

Cummins Intebrake™: The Intebrake™ can reach up to 600 braking HP, which helps control the machine and reduce brake wear.

Cummins Isx Rocker Shaft Torque

Cummins Isx 15 Torque Specs

Dual overhead camshafts: If your ISX was manufactured before 2010, it has a dual camshaft system. The first cam creates high-pressure fuel injection for clean power while the second has a set of lobes to operate the integrated engine brake. The second set of camshafts also moves the intake and exhaust valves. With a high-pressure fuel injection system, a marine engine can produce complete combustion.

High-pressure fuel injection system:The high-pressure system forms a clean and complete combustion phase.

Integrated electronic controls: Engines produced after 2010 rely on an ECM. The engine’s ECM controls the aftertreatment. It also synchronizes interactions between the ABS, transmission, engine brake, cooling fan and other components.

Low maintenance: An ISX engine can run up to 15,000 miles between oil and filter changes.

Mid-stop cylinder liners: Cylinder liners within the ISX have a strong design to allow for variations in coolant chemistry.

Particulate filter:An ISX engine has a fully integrated particulate filter for uncompromised performance by reducing particulate matter.

Single overhead camshaft: Versions made after 2010 have a single camshaft system with a common rail fuel operation that relies on piston pumps to inject diesel.

Variable geometry turbocharger:The turbocharger has a sliding nozzle to boost durability and reliability. Its electric actuation enhances its responses and control for adjustment. The component also delivers a definite increase at any RPM.

Cummins has mastered the engineering process by integrating each possible solution into one unit.

Common Cummins ISX Issues

When you find your ISX engine is experiencing issues, refer to your manufacturer’s manual. Address any problems right away to avoid more severe damage. Here are some tips to keep in mind before making engine repairs:

– Check the dual or single overhead cams.

– Inspect the spring-loaded cam gear and release the tension before unloading.

– Set the idol gear.

– Use a puller tool for the front and back seal.

– Use heavy-duty cams.

– Work with specified parts for ISX engines.

Do you have a single or dual cam ISX? Does it have an EGR system?

When it comes to common ISX issues, some problems may not affect your engine, depending on the year it was made. It’s important to know what version of the marine engine you operate to understand what troubleshooting and repairs are necessary.

For example, engines engineered before 2002 will experience more problems with EGR compared to modern types. In 2008, Cummins began noticing the SCR system experienced failing revolving parts, interfering with the engine’s horsepower. Clogged inlets came about in 2010 when recirculation was occurring, also affecting HP.

Depending on the version you have, common Cummins ISX engine problems involve the turbocharger, EGR, camshafts and timing wedge:

Variable Geometry Turbocharger

The turbocharger is one of the most notorious ISX failures and is expensive to fix. While they are ideal for direct throttle response, VGTs often experience a buildup of carbon, soot, rust and other contaminants. You may feel no response from the engine or an extreme retort at low RPMs. The best fix is to clean the exhaust side of the VGT, replace its parts or swap it for a fixed unit.

EGR System

Another common problem is an EGR valve that leaks. It can cause black smoke and power loss to your ISX engine. Although it’s tricky to diagnose, you can monitor the unit’s coolant to see if leaks are present. If you’re using more coolant than usual, it can be an indication of a leak. Another sign is if you notice white residue from the burnt coolant. EGR system issues are more common in older versions of ISX engines.

Camshaft

Rocker arms within your ISX may be damaging the camshafts, which causes an improper amount of oil to pass. When the rockers hit the camshaft lobes, it flattens them. This deprivation causes your marine or generator application to experience performance issues. You can replace both the camshaft and rockers to deter the problem. Swapping rocker arms for new ones is vital. Otherwise, they will flatten the new camshaft as well.

Timing Wedge

Problems with a timing wedge often happen after you repair or overhaul the camshaft. Wedges have a tendency to wear, which inadvertently alters the camshaft timing, therefore, wrecking the engine’s balance. Fuel injection that occurs at the wrong time can affect the entire system. If it’s too late, it can create soot, contaminating the oil. Over time, a buildup of contamination can form in the oil filter, resulting in a drop in oil pressure.

Cummins Isx15 Flywheel Torque Specs

Avoid the timing wedge issue by changing the oil filter. If the problem seems to improve, you need to retime the ISX engine using a dial indicator. It’s a sensitive procedure, so you may need to rely on the professionals to take over.

Certain ISX engines experience more problems than others, but each issue has a set of simple troubleshooting procedures. One of the best ways to eliminate problems with your Cummins is to conduct preventative and regular maintenance according to your manufacturer’s manual.

Why the Cummins ISX May Be Ideal for You

The Cummins ISX trumps other engine solutions by living up to EPA emission standards and having an advanced fuel economy. The ISX may be the ideal provision, whether you’re a yacht or a workboat owner. Several of the engine’s featured products include:

Cylinder head with valves: With a cylinder head remanufactured to advanced conditions, it functions like new. The new internal components are tested for air decay and are also wet tested. It has chased threads, and mechanics weld any cracks to avoid leaks.

Inframe engine rebuild kit:The rebuild kit includes new parts. The pistons are made from heat-treated steel and have a modern closed-skirt design. With induction-hardened cylinder liners, it delivers improved wear resistance. The rod bearings are made from bi-metal for better strength, durability and fitment.

Fuel injector: A remanufactured ISX fuel injector has new parts ranging from the spill valve, shim and NOP spring to screws and the actuator assembly. It also includes new external O-rings and filters.

Inframe engine rebuild kit with re-ring and fewer pistons: The ISX has an inframe rebuild option for when your pistons are in good shape. It has oil control rings made with precise tangential tension for ideal control, and the gaskets are made with premium materials.

Cummins Isx 15 Flywheel Housing Torque Specs

Cummins isx 15 torque specs diagram

Valve camshaft:If your engine has worn camshafts, they can reduce the amount of horsepower and affect the valve timing. The valve camshaft involves precise remanufacturing.

ISX variable speed propulsion engines are perfect for recreational, commercial and government marine applications. Cummins strives to upgrade and improve each component in their ISX engine series to deliver superior dependability and performance. The marine engine has an exceptional fuel economy compared to other big-bore engines and outstanding braking features.

Cummins continues to expand the X15 series’ components, even into 2020, where their latest version already meets 2021 greenhouse gas regulations and fuel economy standards.

The ISX also has unmatched fuel economy, emissions, performance and cooling systems:

Fuel economy: The ISX has efficient water and fuel pumps which deliver more usable horsepower to your operations. Cummins uses technology to generate optimized combustions and fewer regenerations of the aftertreatment system. The ISX undergoes better fuel economy advancements with each new version.

Emissions: Current ISX engines meet EPA standards along with DOT regulations because of on-board diagnostics that look at optimal emission performances.

Performance: The ISX has a massive range of horsepower, depending on which version suits your application. With a max 2,050 lb.-ft. of peak torque, the engine’s SmartTorque adds 200 lb.-ft. of extra torque when needed. You can tailor the unit’s performance to your specific needs.

Cooling system: The cooling system underwent a size reduction without losing power to increase aerodynamics. It also reduces losses seen in the alternator’s performance and other water pumps. A smaller cooling solution creates an open room, forming cooled air around the engine.

Cummins also continues to improve the combustion chamber to result in fewer active regenerations of the aftertreatment. The ISX has advanced components and featured products to support your marine and generator applications.
