Warning: This manual is moved to https://help.mikrotik.com/docs/display/ROS/CHR

Instructions; Other versions should also be supported following bellow’s procedure. Download Mikrotik Cloud router image chr-6.40.4.img.zip from. MikroTik Routers and Wireless - Software.



  • 2System Requirements
  • 3How to Install CHR
  • 4CHR Licensing
    • 4.1Paid licenses
    • 4.2Free licenses
  • 5Getting the License
  • 7Troubleshooting
    • 7.1Running on VMware ESXi
    • 7.4Using vlans on CHR in various Hypervisors
  • 8Guest tools
    • 8.1VMWare
      • 8.1.5Provisioning
    • 8.2Xen
    • 8.3KVM

Cloud Hosted Router

Cloud Hosted Router (CHR) is a RouterOS version intended for running as a virtual machine. It supports the x86 64-bit architecture and can be used on most of the popular hypervisors such as VMWare, Hyper-V, VirtualBox, KVM and others. CHR has full RouterOS features enabled by default but has a different licensing model than other RouterOS versions.

System Requirements

Minimal requirements:

  • Package version: RouterOS v6.34 or newer
  • Host CPU: 64-bit with virtualization support
  • RAM: 128MB or more
  • Disk: 128MB disk space for the CHR virtual hard drive (Max: 16GB)

Note: The minimum required RAM depends on interface count and CPU count. You can get an approximate number by using the following formula: RAM = 128 + [ 8 × (CPU_COUNT) × (INTERFACE_COUNT - 1) ]


Chr mikrotik download free

CHR has been tested on the following platforms:

  • VirtualBox 5 on Linux and OS X
  • VMWare Fusion 7 and 8 on OS X
  • VMWare ESXi 6.5
  • Qemu 2.4.0.1 on Linux and OS X
  • Hyper-V on Windows Server 2008r2, 2012 and Windows 10 (Only Generation 1 Hyper-V virtual machine is supported at the moment)
  • Xen Project 4.6.5
  • Xen Server 7.1

Warning: Hypervisors that provide paravirtualization are not supported.


Usable Network and Disk interfaces on various hypervisors:

  • ESX:
    • Network: vmxnet3, E1000
    • Disk: IDE, VMware paravirtual SCSI, LSI Logic SAS, LSI Logic Parallel
  • Hyper-V:
    • Network: Network adapter, Legacy Network adapter
    • Disk: IDE, SCSI
  • Qemu/KVM:
    • Network: Virtio, E1000, vmxnet3 (optional)
    • Disk: IDE, Sata, Virtio
  • Xen Project:
    • Network: E1000, rtl8193, netfront
    • Disk: IDE, Sata
  • VirtualBox
    • Network: E1000, rtl8193
    • Disk: IDE, Sata, SCSI, SAS

Note: SCSI controller Hyper-V and ESX is usable just for secondary disks, system image must be used with IDE controller!


Warning: We do not recommend using E1000 network interface if better synthetic interface options are available on specific Hypervisor!


How to Install CHR

We provide 4 different virtual disk images to choose from. Note that they are only disk images, and you can't simply run them.

  • RAW disk image (.img file)
  • VMWare disk image (.vmdk file)
  • Hyper-V disk image (.vhdx file)
  • VirtualBox disk image (.vdi file)

Steps to install CHR

  1. Download virtual disk image for your hypervisor
  2. Create a guest virtual machine
  3. Use previously downloaded image file as a virtual disk drive
  4. Start the guest CHR virtual machine
  5. Log in to your new CHR. Default user is 'admin', without password

Please note that running CHR systems can be cloned and copied, but the copy will be aware of the previous trial period, so you cannot extend your trial time by making a copy of your CHR. However, you are allowed to license both systems individually. To make a new trial system, you need to make a fresh installation and reconfigure RouterOS.

Installing CHR

  • VMWare Fusion / Workstation and ESXi 6.5

CHR Licensing

The CHR has 4 license levels:

  • free
  • p1perpetual-1 ($45)
  • p10perpetual-10 ($95)
  • p-unlimitedperpetual-unlimited ($250)

60-day free trial license is available for all paid license levels. To get the free trial license, you have to have an account on MikroTik.com as all license management is done there.

Perpetual is a lifetime license (buy once, use forever). It is possible to transfer a perpetual license to another CHR instance.A running CHR instance will indicate the time when it has to access the account server to renew it's license. If the CHR instance will not be able to renew the license it will behave as if the trial period has ran out and will not allow an upgrade of RouterOS to a newer version.

After licensing a running trial system, you must manually run the /system license renew function from the CHR to make it active. Otherwise the system will not know you have licensed it in your account. If you do not do this before the system deadline time, the trial will end and you will have to do a complete fresh CHR installation, request a new trial and then license it with the license you had obtained.

Mikrotik Chr Image Download

LicenseSpeed limitPrice
Free1MbitFREE
P11Gbit$45
P1010Gbit$95
P-UnlimitedUnlimited$250

Paid licenses

p1

p1 (perpetual-1) license level allows CHR to run indefinitely. It is limited to 1Gbps upload per interface. All the rest of the features provided by CHR are available without restrictions. It is possible to upgrade p1 to p10 or p-unlimited After the upgrade is purchased the former license will become available for later use on your account.

p10

p10 (perpetual-10) license level allows CHR to run indefinitely. It is limited to 10Gbps upload per interface. All the rest of the features provided by CHR are available without restrictions. It is possible to upgrade p10 to p-unlimited After the upgrade is purchased the former license will become available for later use on your account.

p-unlimited

The p-unlimited (perpetual-unlimited) license level allows CHR to run indefinitely. It is the highest tier license and it has no enforced limitations.

Free licenses

There are several options to use and try CHR free of charge.

free

The free license level allows CHR to run indefinitely. It is limited to 1Mbps upload per interface. All the rest of the features provided by CHR are available without restrictions. To use this, all you have to do is download disk image file from our download page and create a virtual guest.

60-day trial

In addition to the limited Free installation, you can also test the increased speed of P1/P10/PU licenses with a 60 trial.

You will have to have an account registered on MikroTik.com. Then you can request the desired license level for trial from your router that will assign your router ID to your account and enable a purchase of the license from your account. All the paid license equivalents are available for trial. A trial period is 60 days from the day of acquisition, after this time passes, your license menu will start to show 'Limited upgrades', which means that RouterOS can no longer be upgraded.

If you plan to purchase the selected license, you must do it within 60 days of the trial end date. If your trial ends, and there are no purchases within 2 months after it ended, the device will no longer appear in your MikroTik account. You will have to make a new CHR installation to make a purchase within the required time frame.

To request a trial license, you must run the command '/system license renew' from the CHR device command line. You will be asked for the username and password of your mikrotik.com account.

Warning: If you plan to use multiple virtual systems of the same kind, it may be possible that the next machine has the same systemID as the original one. This can happen on certain cloud providers, such as Linode. To avoid this, after your first boot, run the command '/system license generate-new-id' before you request a trial license. Note that this feature must be used only while CHR is running on free type of RouterOS license. If you have already obtained paid or trial license, do not use regenerate feature since you will not be able to update your current key any more


Getting the License

After the initial setup a CHR instance will have a free license assigned. From there, it is possible to upgrade the license to a higher tier. Once you have a trial license all the work with the license is done on the account server where it is possible to upgrade license to a higher tier unless it is p-unlimited already.

Upgrade from free to p1 or higher

Initial upgrade from the free tier to anything higher than that incurs CHR instance registration on the account server. To do that you have to enter your MikroTik.com username and password and a desired license level you want to acquire. As a result, a CHR ID number will be assigned to your account on the account server and 60-day trial created for that ID. There are 2 ways to obtain a license - using WinBox or RouterOS command line interface:

Using WinBox (Sytem -> License menu):

Using command line interface:

To acquire a higher level trial, set up a new CHR instance, renew the license and select the desired level.

To upgrade from a Trial license to Paid go to MikroTik.com account server and choose 'all keys' in Cloud Hosted Router (CHR) section:

You will be presented with a list of your CHR machines and licenses:

To upgrade from a Trial to a Paid license click 'Upgrade', choose the desired license level (it can be different than the level of the trial license) and click 'Upgrade key':

Choose the payment method:

It is possible to pay using account balance (deposit), credit card (CC), PayPal or using Balance (prepaid) key (if you have any).

Upgrade from higher tier up

Only an upgrade to a higher tier is possible at the moment (for paid licenses only) and that is done in the account server. For changes to take place on the router itself renew command should be issued. When the router already has any kind of trial or paid license, the license level you set for the renew command is not important anymore, it is mandated by [license.mikrotik.com account server]. Possible upgrades are as follows:

  • p1 upgrade to p10
  • p1 upgrade to p-unlimited
  • p10 upgrade to p-unlimited

License Update

In '/system license' menu router will indicate the time next-renewal-at when it will attempt to contact server located on licence.mikrotik.com. Communication attempts will be performed once an hour after the date on next-renewal-at and will not cease until the server responds with an error.If deadline-at date is reached without successfully contacting the account server, the router will consider that license has expired and will disallow further software updates. However, router will continue to work with the same license tier as before.

Troubleshooting

Running on VMware ESXi

Changing MTU

VMware ESXi supports MTU of up to 9000 bytes. To get the benefit of that, you have to adjust your ESXi installation to allow a higher MTU. Virtual Ethernet interface added after the MTU change will be properly allowed by the ESXi server to pass jumbo frames. Interfaces added prior to MTU change on the ESXi server will be barred by the ESXi server (it will still report old MTU as maximum possible size). If you have this, you have to re-add interfaces to the virtual guests.

Example. There are 2 interfaces added to the ESXi guest, auto-detected MTU on the interfaces show MTU size as it was at the time when the interface was added:

Mikrotik Chr Proxmox

Using bridge on Linux

If Linux bridge supports IGMP snooping, and there are problems with IPv6 traffic it is required to disable that feature as it interacts with MLD packets (multicast) and is not passing them through.

Packets not passing from guests

Chr Mikrotik Download

The problem: after configuring a software interface (VLAN, EoIP, bridge, etc.) on the guest CHR it stops passing data to the outside world beyond the router.

The solution: check your VMS (Virtualization Management System) security settings, if other MAC addresses allowed to pass if packets with VLAN tags allowed to pass through. Adjust the security settings according to your needs like allowing MAC spoofing or certain MAC address range. For VLAN interfaces, it is usually possible to define allowed VLAN tags or VLAN tag range.

Using vlans on CHR in various Hypervisors

In some of hypervisors before Vlans can be used on VMs they need to first be configured on hypervisor it self.

ESXI

Mikrotik chr download for gns3

Enable Promiscuous mode in port group or virtual switch that you will use for specific VM.

ESX documentation:

Hyper-V

Hyper-V documentation:

bhyve hypervisor

It wont be possible to run CHR on this hypervisor. CHR cannot be run as paravirtualized platform.

Linode

When creating multiple Linodes with the same disk size, new Linodes will have the same systemID. This will cause issues to get a Trial/Paid license. To avoid this, run the command /system license generate-new-id after the first boot and before you request a trial or paid license. This will make sure the ID is unique.


Some useful articles:

Specific vlan is untagged by nic interface:

Allow passing other vlans:

Guest tools

VMWare

Time synchronization

Must be enabled from GUI ('Synchronize guest time with host'). Backwards synchronization is disabled by default - if guest is ahead of host by more than ~5 seconds, synchronization is not performed

Power operations

  • poweron and resume scripts are executed (if present and enabled) after poweron and resume operations respectively.
  • poweroff and suspend scripts are executed before poweroff and suspend operations respectively.
  • If scripts take longer than 30 seconds or contain errors, the operation fails
  • In case of failure, retrying the same operation will ignore any errors and complete successfully
  • Failed script output is saved to file (e. g. 'poweroff-script.log', 'resume-script.log' etc)
  • Scripts can be enabled/disabled from hypervisor GUI ('run VMware Tools Scripts') or by enbaling/disabling scripts from console

Quiescing/backup

Guest filesystem quiescing is performed only if requested.

  • freeze script is executed before freezing the filesystem
  • freeze-fail script is executed if hypervisor failed to prepare for snapshot or if freeze script failed
  • thaw script is executed after snapshot has been taken
  • Script run time is limited to 60 seconds
  • freeze script timeouts and errors result in backup operation being aborted
  • FAT32 disks are not quiesced
  • Failed script output is saved to file (e. g. 'freeze-script.log', 'freeze-fail-script.log', 'thaw-script.log')

Guest info

Networking, disk, and OS info is reported to hypervisor every 30 seconds (GuestStats (memory) are disabled by default, can be enabled by setting 'guestinfo.disable-perfmon = 'FALSE' in VM config).

  • The order, in which network interfaces are reported, can be controlled by setting 'guestinfo.exclude-nics', 'guestinfo.primary-nics' and 'guestinfo.low-priority-nics' options. Standard wildcard patterns can be used.

Provisioning

Can use the ProcessManager from vim API to execute scripts. Python bindings are available

  • Main data structure: GuestProgramSpec
    • The workingDirectory and envVariables members are ignored
    • programPath must be set to either 'inline' or 'import'
    • If programPath is 'inline', arguments are interpreted as script text
    • If programPath is 'import', arguments are interpreted as file path

After using GuestProgramSpec together with an instance of GuestAuthentication as arguments to StartProgramInGuest unique JobID is obtained.

Script progress can be tracked by using the ListProcessesInGuest command. ListProcessesInGuest accepts an array of job id's; passing an empty array will report on all jobs started from API

  • ListProcessesInGuest returns an array of GuestProcessInfo instances:
    • pid field is set to JobID
    • endTime is only set after completion
    • exitCode is set to 0 on success and -1 on error
    • name is set to 'inline' or 'import' (same as programPath in GuestProgramSpec)

Information about completed jobs is kept around for ~1 minute, or untill ListProcessesInGuest (with the corresponding JobID) is called. If the script fails, a file named 'vix_job_$JobID$ .txt' containing the script output is created. Script run time is limited to 120 seconds and script output is not saved on timeout,

  • The vmrun command runScriptInGuest can also be used
  • The PowerCLI cmdlet Invoke-VMScript is not supported
  • Host/guest file transfer is not supported
Python example

Xen

Network, disk, memory and OS info is reported to hypervisor every 30 seconds

  • On older hosts (pre 21.06.2017) only the first ipv4 address assigned to interface is visible

Provisioning

Base-64 encoded strings written to (domain local) xenstore path ('vm-data/provision/script') are decoded and interpreted a script-text. Status ('ready', 'running', 'error') is reported in 'vm-data/provision/script/status'. Scripts are accepted only if 'status' != 'running'. Base 64 encoded script output (if any) is written to 'vm-data/provision/script/otuput'.

  • When creating a VM scripts can be provided by using xenapi (VM.add_to_xenstore_data)

KVM

QEMU guest agent is available. Supported agent commands can be retrieved by using guest-info command. Host-guest file transfer can be performed by using guest-file-* commands. Guest networking information can be retrieved by using the guest-network-get-interfaces command.

  • Scripts can be executed by using the guest-exec command together with the GuestExec data structure:
    • If the path member is provided, the corresponding file is executed
    • If the path member is not set and input-data member is provided, input-data value is used as script input
    • If capture-output is set, script output is reported back
    • args and env members are not used
  • Script job progress can be monitored with guest-exec-status command. The GuestExecStatus data structure is populated as follows:
    • On success exitcode member is set to 0
    • If the script timed out exitcode is set to 1
    • If the script contained errors exitcode is set to -1
    • signal member is not set
    • The err-data member is not used
    • If capture-output was true, Base64 encoded script output is stored in out-data


  • An additional agent channel ('chr.provision_channel') is also available

Proxmox

Some agent commands can be issued by using Proxmox REST api. Guest filesystem quiescing is automatically performed when taking a snapshot

  • Enabling 'chr.provision-agent' for remote access on port 1234

In host shell:

Download Mikrotik Chr

  • Disabling 'chr.provision-agent'

In host shell:

  • Providing remote access to default agent on port 1234

In host shell:

Mikrotik-chr.gns3a Download

Guest agent python example


[Top | Back to Content]

Retrieved from 'https://wiki.mikrotik.com/index.php?title=Manual:CHR&oldid=34165'

After installation RouterOS runs intrial mode. You have 24 hours to register for Level1 (Free demo) or purchase a Level 4,5 or 6 license and paste a valid key.

Level 3 is a wireless station (client or CPE) only license.For x86 PCs, Level3 is not available for purchase individually.

Level 2 was a transitional license from old legacy (pre 2.8) license format. These licenses are not available any more, if you have this kind of license, it will work, but to upgrade it - you will have to purchase a new license.

The difference between license levels is shown in the table below.

Level number0 (Trial mode)1 (Free Demo)3 (WISP CPE)4 (WISP)5 (WISP)6 (Controller)
Priceno keyregistration requirednot for sale$45$95$250
Wireless AP mode (PtM)24h trial-noyesyesyes
PPPoE tunnels24h trial1200200500unlimited
PPTP tunnels24h trial1200200500unlimited
L2TP tunnels24h trial1200200500unlimited
OVPN tunnels24h trial1200200unlimitedunlimited
EoIP tunnels24h trial1unlimitedunlimitedunlimitedunlimited
VLAN interfaces24h trial1unlimitedunlimitedunlimitedunlimited
Queue rules24h trial1unlimitedunlimitedunlimitedunlimited
HotSpot active users24h trial11200500unlimited
User manager active sessions24h trial1102050Unlimited


All Licenses:

  • never expire (a running and licensed router can be used indefinitely)
  • can use unlimited number of interfaces
  • are for one installation each
  • offer unlimited software upgrades

CHR License Levels

License levels described until now do not apply to Cloud Hosted Routers (CHRs). CHR is a RouterOS version intended for running as a virtual machine. It has its own 4 license levels as well as trial where you can test any of the paid license levels for 60 days.

60-day free trial license is available for all paid license levels. To get the free trial license, you have to have an account onMikroTik.comas all license management is done there.

Perpetual is a lifetime license (buy once, use forever). It is possible to transfer a perpetual license to another CHR instance. A running CHR instance will indicate the time when it has to access the account server to renew it's license. If the CHR instance will not be able to renew the license it will behave as if the trial period has ran out and will not allow an upgrade of RouterOS to a newer version.

After licensing a running trial system, youmustmanually run the/system license renewcommand from the CHR to make it active. Otherwise the system will not know you have licensed it in your account. If you do not do this before the system deadline time, the trial will end and you will have to do a complete fresh CHR installation, request a new trial and then license it with the license you had obtained.

LicenseSpeed limitPriceDescription
Free1MbitFREEThe free license level allows CHR to run indefinitely. It is limited to 1Mbps upload per interface. All the rest of the features provided by CHR are available without restrictions. To use this, all you have to do is download disk image file from our download page and create a virtual guest.
P11Gbit$45P1 (perpetual-1) license level allows CHR to run indefinitely. It is limited to 1Gbps upload per interface. All the rest of the features provided by CHR are available without restrictions. It is possible to upgrade p1 to p10 or p-unlimited After the upgrade is purchased the former license will become available for later use on your account.
P1010Gbit$95P10 (perpetual-10) license level allows CHR to run indefinitely. It is limited to 10Gbps upload per interface. All the rest of the features provided by CHR are available without restrictions. It is possible to upgrade p10 to p-unlimited After the upgrade is purchased the former license will become available for later use on your account.
P-UnlimitedUnlimited

$250

The p-unlimited (perpetual-unlimited) license level allows CHR to run indefinitely. It is the highest tier license and it has no enforced limitations.
60-day Trial
FREE

In addition to the limited Free installation, you can also test the increased speed of P1/P10/PU licenses with a 60 trial.

You will have to have an account registered on MikroTik.com. Then you can request the desired license level for trial from your router that will assign your router ID to your account and enable a purchase of the license from your account. All the paid license equivalents are available for trial. A trial period is 60 days from the day of acquisition, after this time passes, your license menu will start to show 'Limited upgrades', which means that RouterOS can no longer be upgraded.

Note that if you plan to purchase the selected license, you must do it before 60 days trial ends. If your trial has ended, and there are no purchases within 2 months, the device will no longer appear in your MikroTik account. You will have to make a new CHR installation to make a purchase within the required time frame.

To request a trial license, you must run the command '/system license renew' from the CHR device command line. You will be asked for the username and password of your mikrotik.com account.


Warning: If you plan to use multiple virtual systems of the same kind, it may be possible that the next machine has the same SystemID as the original one. This can happen on certain cloud providers, such as Linode. To avoid this, after your first boot, run the command '/system license generate-new-id' before you request a trial license. Note that this feature must be used only while CHR is running on free type of RouterOS license. If you have already obtained paid or trial license, do not use regenerate feature since you will not be able to update your current key any more

To use multiple virtual machines, download the disk image from our webpage, and make as many copies, as you need virtual machines. Then make new virtual machine system from each virtual disk image.

Make sure to make copies of the Disk Image before you run or register the downloaded file.

It is a special key which is issued by the MikroTik support ream if you accidentally lose the license on a x86 instance running RouterOS, and the Mikrotik Support employee decides that it is not directly your fault. It costs 10$ and has the same features as the key that you lost.

Note that before issuing such key, Mikrotik Support can ask you to prove that the old drive has failed, in some cases, this means sending us the dead drive.

Replacement key request

1)Go to your account management in mikrotik.com and fill the 'support contact form' or write a direct e-mail to [email protected]

  • Please provide detailed information about why replacement key is required

2)Send required info to MikroTik support department.

3)Re-check your account after support staff has confirmed that replacement key has been added to your account. Select the section 'Make a key from replacement key'

4)Select the appropriate license level on which you wish to perform the replacement

5)Enter the new 'software-ID'

6)Proceed to checkout by pressing 'Add license replacement to cart' and finish the payment

7)An e-mail will be sent to your profile containing the new license.

  • You can also find the newly generated key in the section 'Search and view all keys' under the folder 'Purchased YYYY' where 'YYYY' is the current Year

We may issue only one replacement key per one original key, using replacement key procedure twice for one key will not be possible. In cases like this new key for this RouterOS device must be purchased.

Where can I buy a RouterOS license key?

MikroTik devices come preinstalled with a license and no purchase is needed.

To obtain a higher level license, or to obtain a license for a x86 PC installation, you must register anaccount on our webpage, and in there, use the option 'Purchase a RouterOS license key'.

Mikrotik

If I have purchased my key elsewhere

You must contact the company who sold you the license, they will provide the support.

If I have a license and want to put it on another account?

You can give access to keys with the help ofVirtual Folders

The only kind of licenses, that could be transferred to another Account is a prepaid key, which is purchased or is got from MUM. Prepaid keys got as a gift from the Training are not transferable.
To transfer purchased prepaid key navigate to 'Transfer prepaid keys' in the section 'ROUTEROS KEYS' on your MikroTik Account.

If I have lost a license on my device?

If for some reason you have lost license from your router, upgrade router to the latest RouterOS version available and use 'Request license key' in your mikrotik.com account. Use soft-id and serial number available under System/License menu in RouterOS when requesting license. Apply received license or contact [email protected] if request feature do not work.

If the license was lost due to repairs and they were not done via the distributor under warranty, you will have to purchase a new RouterOS license for the full price!

Can I Format or Re-Flash the drive?

Formatting, and Re-Imaging the drive with non-MikroTik tools (like DD and Fdisk) will destroy your license! Be very careful and contact mikrotik support before doing this. It is not recommended, as MikroTik support might deny your request for a replacement license. For this use MikroTik provided tools Netinstall or CD-install that are freely available from our download page.

How many computers can I use the License on?

At the same time, the RouterOS license can be used only in one system. The License is bound to the HDD it is installed on, but you have the ability to move the HDD to another computer system. You cannot move the License to another HDD, neither can you format or overwrite the HDD with the RouterOS license. It will be erased from the drive, and you will have to get a new one. If you accidentally removed your license, contact the support team for help.

Can I temporary use the HDD for something else, other than RouterOS?

As stated above, no.

Can I move the license to another HDD ?

If your current HDD drive is destroyed, or can no longer be used, it is possible to transfer the license to another HDD. You will have to request a replacement key (see below) which will cost 10$

Must I type the whole key into the router?

No, simply copy it and paste in the menuSystem-->License,

Can I install another OS on my drive and then install RouterOS again later?

No, because if you use formatting, partitioning utilities or tools that do something to the MBR, you will lose the license and you will have to make a new one. This process is not free (see Replacement Key above)

I lost my RouterBOARD, can you give me the license to use on another system?

Download mikrotik chr

MikroTik hardware comes with an embedded license. You cannot move this license to a new system in any way, this includes any upgrades applied to the MikroTik router while it was still working.

Licenses Purchased from Resellers

The keys that you purchase from other vendors and resellers are not in your account. Your mikrotik.com account only contains licenses purchased from MikroTik directly. However, you can use the 'Request key' link in your account, to get the key into your account for reference, or for some upgrades (if available).

I am not using the software, can you terminate my license?

Mikrotik Chr Download For Gns3

The licenses are stand alone keys and MikroTik does not have any remote control over your devices. Therfore, we are unable to verify if you use your license or not. This is why MikroTik cannot terminate any issued licenses.
